Functionality

Although this could be considered ethereal and academic in nature, this has turned into a full-
fledged application. In one test, the researchers identified seven security issues. Six of these
were new and one was acknowledged with CVE-2014-9798. With the six new issues, five had
been acknowledged by the bootloader vendors (Cimpanu, 2017; Brenner, 2017; Redini,
Machiry, Das, Fratantonio, Bianchi, Gustafson, Shoshitaishvili, Kruegel, & Vigna, 2017). These
vulnerabilities may provide the attacker the opportunity to carry out permanent DoS attacks, to
gain root rights which would then allow the OS to be unlocked and breach the CoT, and also
insert the attacker’s arbitrary code (Cimpany, 2017; Brenner, 2017).

This is not applicable to all the manufacturers. To date, this does affect the Huawei/HiSilicon
chipset (Huawei P8 ALE-L23), NVIDIA Tegra chipset (Nexus 9), MediaTeck chipset (Sony
Xperia XA), and Qualcomm’s new and old LK bootloader (Brenner, 2017). The previously noted
issue was related to the Qualcomm LK bootloader that was previously used.

Availability

The tool is available on GitHub in the repository (https://github.com/ucsb-seclab/BootStomp,
https://github.com/ucsb-seclab/BootStomp/blob/master/README.md, https://github.com/ucsb-
seclab/BootStomp/tree/master/tools, https://github.com/ucsb-
seclab/BootStomp/tree/master/toos/huawei_tools).

Evaluations for the Huawei, Nexus, Qualcomm, and Xperia chips are located at
https://github.com/ucsb-seclb/BootStomp/tree/master/evaluation.

In review of the reports, the tool provides a plethora of data and information. As an example, the
tool has a full, and thorough analysis of the Huawei bootloader (https://github.com/ucsb-
seclab/BootStomp/blob/master/evaluation/huawei_p8/taint_analysis.txt) for review. These note
the issues present, along with where these are located. This tool may not be a panacea,
however is exceptional for testing hardware modules which have these and potentially other
chips.

Resources

Brenner, B. (2017, September 6). Fur flies over android bootloader flaws: Here’s what you need
to know. Retrieved from https://nakedsecurity.sophos.com/2017/09/06/fur-flies-over-android-
bootloader-flaws-heres-what-you-need-to-know/

Cimpanu, C. (2017, September 2). Vulnerabilities discovered in mobile bootloaders of major
vendors. Retrieved from https://www.bleepingcomputer.com/news/security/vulnerabilities-
discovered-in-mobile-bootloaders-of-major-vendors/

Pentestit. (2017, August 1). Bootstomp: Find mobile device bootloader vulnerabilities. Retrieved
from http://pentestit.com/bootstomp-find-mobile-device-bootloader-vulnerabilities/
